Thermaltake Smart BX1 550W 80+Bronze SMPS
Features :
- Ultra Quiet Hydraulic Bearing Fan
- All Flat Black Cables
- 80PLUS® Bronze 230V EU Internal Certified
- Continuous power at 40°C
- 5Years Limited Brand Warranty
Original price was: ₹6,990.00.₹3,859.00Current price is: ₹3,859.00. Including GST
Warranty
5 Years Limited by Brand
Return
7 Days Return
Delivery
Fast Delivery
Trust
100% Genuine
Secure
Payments
11
People watching this product now!
Thermaltake Smart BX1 550W 80+ Bronze Certified Power Supply Unit
Built to deliver 80 PLUS Bronze with 88% power efficiency, the Smart BX1 series is available in 450W – 750W models. Constructed with a 120mm hydraulic bearing fan, Japanese main capacitors and other premium components to help deliver a continuous and stable power output at 40℃, near silent operation and reliable performance. With an ample 5-year warranty, the Smart BX1 is able to satisfy the market, where value-oriented users are looking for a new power supply with all the latest features.
Ultra Quiet 120mm Hydraulic Bearing Fan
Featuring a 120mm hydraulic bearing fan with intelligent RPM controls to help guarantee superior cooling performance and near silent operation.
Low Ripple Noise
All ripples are lower than 80mV on +12V, and lower than 40mV on +5V or +3.3V from 0% to 100% load to ensure a stable operation and keep your performance-critical components, such as high-end graphics cards, to function reliably for longer.
Premium Japanese Main Capacitor
Providing great durability as well as offering the highest stability, while remaining reliable.
High Amperage Single +12V Rail
Powerful single +12V rail ensures a stable and reliable supply to other PC components.
80 PLUS Gold Certified and Intel C6/C7 States Ready
Smart BX1 series saves energy through its high energy efficiency up to 88% and is certified to 80 PLUS® Bronze. It has been optimized to work with all generations of Intel’s processors to achieve maximum energy saving.
Technical Specifications :
| P/N | PS-SPD-0550NNFABx-1 |
| watts | 550W |
| RGB Fan | No |
| Form Factor | ATX |
| Model | SPD-550AH2NKB | SPD-550AH2NLB | SPD-550AH2NCB |
| Type | ATX 12V v2.3 and EPS v2.92 |
| Max. Output Capacity | 550W |
| Color | Black |
| Dimension ( W / H / D ) | 150mm(W) x 86mm(H) x 140mm(D) |
| PFC (Power Factor Correction) | Active PFC |
| Power Good Signal | 100-500 msec |
| Hold Up Time | > 16msec at 70% of full load |
| Input Current | 10A max.| 5 – 10A | 8A max. |
| Input Frequency Range | 50Hz – 60Hz| 47Hz – 63Hz | 47Hz – 63Hz |
| Input Voltage | 100V – 240V~ |
| OPERATING TEMPERATURE | 5°C to + 40°C | 5°C to + 40°C | 0°C to + 40°C |
| Operating Humidity | 20% to 85%, non-condensing | 20% to 85%, non-condensing | 20% to 90%, non-condensing |
| Storage Temperature | -40°C to + 55°C | -40°C to + 55°C | -40°C to + 70°C |
| Storage Humidity | 10% to 95%, non-condensing | 10% to 95%, non-condensing | 5% to 95%, non-condensing |
| COOLING SYSTEM | 12cm Hydraulic bearing fan |
| Efficiency | Meet 80 PLUS®Bronze at 115Vac input. |
| MTBF | 100,000 hrs minimum |
| Safety Approval | CE/CB/TUV/ UL/ FCC/ BSMI |
| PCI-E 6+2pin | 2 |
| Weight | 2.5 kg |
|---|---|
| Dimensions | 11 × 26 × 21 cm |
| Brands Select Brand | |
| Color Please Select Color | |
| Country of Origin | China |
| Price Range | 500-4999 |
| Product Type | |
| Warranty |
